Answer the whole of this question on a sheet of plain paper.
(a.) Construct a quadrilateral PQRS in which PQ = 10cm, angle SPQ = 70°, QR = 6.5cm, PS = 5cm, and SR = 7cm.
(c.) On your diagram, construct the locus of points within the quadrilateral PQRS which are
(d.) L is a point inside quadrilateral PQRS such that it is 3cm from PQ and equidistant from PS and SR.
(e.) M is another point inside quadrilateral PQRS such that it is less than or equal to 3cm from PQ and nearer
to PS than to SR.
Indicate clearly, by shading, the region in which M must lie.
The steps in constructing the quadrilateral are:
(1.) Using a ruler, measure and draw $PQ = 10cm$
(2.) Using a protractor with its centre at
P, measure 70° from $PQ$ and mark a point accordingly.
Draw a ray from
P to the point
(3.) Using a compass set to 5cm, mark a point on the ray drawn in Step 2.
Label the point,
S
This implies that $PS = 5cm$ and $\angle SPQ = 70^\circ$
(4.) With the centre at
Q, use a compass to measure a length of 6.5cm and draw an arc
(5.) With the centre at
S, use a compass to measure a length of 7cm and draw an arc
(6.) At the point of intersection of the two arcs, label the point,
R
(7.) Join the line segment, $QR$
(8.) Join the line segment, $SR$
(a.) The quadrilateral PQRS is constructed as shown:
(b.) $\angle PQR = 77^\circ$
The locus of points at a fixed distance from the straight line is a line parallel to it.
So, we shall draw a parallel line segment to the line segment, $PQ$
One way to do this is to construct perpendicular lines at
P and
Q
Then, we measure off 3cm from each of the points and join the parallel line connecting what we measured.
(1.) Extend the horizontal line of $PQ$ from both sides: the left hand side (LHS) and the right hand side
(RHS)
(2.) With the centre at
Q, use a compass and draw arcs that intersect $PQ$ on both sides
(3.) Measure a reasonable length, with the centre at the point on the arc on the LHS, draw arc above and below
Q
(4.) Using the same length, with the centre at the point on the arc on the RHS, draw arcs that intersect the
previous arcs.
(5.) Draw the perpendicular line joining the intersection of both arcs and passing through
P
(6.) Repeat the same process to draw the perpendicular line passing through
Q
(7.) Measure a length of 3cm along the perpendicular line from point
P and along the perpendicular line
from point
Q
(8.) Join the points marked 3cm from
P and
Q.
The resulting line is parallel to $PQ$
(c.) (i.) The locus of points within the quadrilateral PQRS which is 3cm from PQ is:
The locus of points equidistant from two intersecting lines is the angle bisector of the angle formed by the
lines.
So, we need to bisect $\angle PSR$
With the centre at
S, use a compass and draw an arc that cuts $PS$ and $SR$.
From the point of intersection of the arc and $PS$, draw arcs over
S
From the point of intersection of the arc and $SR$, draw arcs that intersect the previously-drawn arcs over
S
Join
S to the point where the two arcs intersect.
This line is the angle bisector of $\angle PSR$.
It is the locus of points equidistant from the line segments $PS$ and $SR$
(c.) (ii.) The locus of points within the quadrilateral PQRS which is equidistant from PS and SR is:
Point
L is the intersection of the two loci drawn from question (c.).
Label it accordingly.
(d.) The point L is labeled as shown:
Less than or equal to 3cm from PQ: This implies that
M must lie in the region between line segments
$PQ$ and the parallel line 3cm above it.
Nearer to PS than to SR: This implies that
M must lie on the side of the angle bisector nearer to $PS$
(e.) The shaded region in which M must lie is shown:
